glift::WrappedPrim Class Reference

#include <wrappedPrim.h>

Inheritance diagram for glift::WrappedPrim:

List of all members.

---

Detailed Description

FactoryPrimGL - A factory class for PrimGL classes.

• This class stores a PrimGL pointer for the derived classes.
• This class can only be constructed by a derived type and can never
  be default-constructed.
• Subclasses instantiate the base class and then does not have to handle the
  repetitive virtual functions that will be identical for all subclasses
  that use only a single PrimGL object.

Definition at line 41 of file wrappedPrim.h.

Public Member Functions
virtual	~WrappedPrim ()
virtual const gutz::arrayo2f &	vert () const
virtual const gutz::arrayo2f &	texCoord () const
	Acessors.
virtual const gutz::arrayo2f &	texCoord (int t) const
virtual int	numVerts () const
virtual bool	hasTexCoords () const
	Texture coordinate interface.
virtual void	bindTexCoords (const MultiPrimTexCoord *texCoords)
virtual void	bindTexCoords (const MultiTexCoord *texCoords)
virtual void	bindIndices (const MultiPrimIndices *indices)
	Vertex indices interface.
virtual void	bindIndices (const gutz::arrayw1ui *indices)
virtual void	releaseIndices ()
virtual void	releaseTexCoords ()
virtual MultiPrimTexCoord *	genTexCoords (const Shader *shader)
	The handler function. Redefine if primitive should generate texture coordinates.
void	draw ()
void	compile ()
virtual void	setErrStream (std::ostream *os)
	Where do you want gl errors to go? they must go somewhere, so don't set it to zero please.
virtual std::ostream *	getErrStream () const
	Where are gl errors going?
Protected Member Functions
	WrappedPrim ()
	WrappedPrim (PrimGL *prim)
	WrappedPrim (const WrappedPrim &rhs)
WrappedPrim &	operator= (const WrappedPrim &rhs)
virtual void	drawDef ()
	DrawableGLI interface.
virtual const gutz::vec3f &	scale () const
void	init (PrimGL *prim)
virtual bool	isCompiled () const
	Redefine this for specific draw functions.
void	err (const char *where, const char *when=0) const
	error
std::ostream &	err () const
	a simpler way, just use the stream! only for always print, this one automatically adds the objects name
void	derr (const char *where, const char *when=0) const
	debug error
bool	glerr (const char *where, const char *when=0) const
	gl error report only in debug mode, only if there is an error, if so return true
std::ostream &	estr () const
	this one just gives you the stream
Protected Attributes
std::ostream *	m_err

---

Constructor & Destructor Documentation

virtual glift::WrappedPrim::~WrappedPrim (   )  [inline, virtual]

Definition at line 44 of file wrappedPrim.h.

glift::WrappedPrim::WrappedPrim (   )  [inline, protected]

Definition at line 60 of file wrappedPrim.h.

glift::WrappedPrim::WrappedPrim (  PrimGL *  prim  )  [inline, protected]

Definition at line 61 of file wrappedPrim.h.

glift::WrappedPrim::WrappedPrim (  const WrappedPrim &  rhs  )  [inline, protected]

Definition at line 62 of file wrappedPrim.h. References m_prim.

---

Member Function Documentation

virtual void glift::WrappedPrim::bindIndices (  const gutz::arrayw1ui *  indices  )  [inline, virtual]

Implements glift::RawPrim. Definition at line 55 of file wrappedPrim.h. References indices.

virtual void glift::WrappedPrim::bindIndices (  const MultiPrimIndices *  indices  )  [inline, virtual]

Vertex indices interface. Implements glift::RawPrim. Definition at line 54 of file wrappedPrim.h. References indices. Referenced by glift::SubdivPlanarQuadS::bindQuads().

virtual void glift::WrappedPrim::bindTexCoords (  const MultiTexCoord *  texCoords  )  [inline, virtual]

Implements glift::RawPrim. Definition at line 53 of file wrappedPrim.h.

virtual void glift::WrappedPrim::bindTexCoords (  const MultiPrimTexCoord *  texCoords  )  [inline, virtual]

Implements glift::RawPrim. Definition at line 52 of file wrappedPrim.h.

void DrawableGLI::compile (   )  [virtual, inherited]

Implements glift::Compilable. Definition at line 57 of file drawableGLI.cpp. References glift::DispList::compile(), and glift::g_compiling.

void glift::GliftObject::derr (  const char *  where, const char *  when = 0 )  const [inline, protected, inherited]

debug error Definition at line 122 of file gliftObject.h. References glift::GliftObject::m_err.

void DrawableGLI::draw (   )  [inherited]

Definition at line 34 of file drawableGLI.cpp. References glift::DrawableGLI::drawDef(), glift::DispList::isCompiled(), and glift::DispList::issue(). Referenced by drawDef(), glift::ShadedPrim::drawDef(), VolRenAlgBase::drawTris(), and glift::ShadedPrim::ShadedPrim().

virtual void glift::WrappedPrim::drawDef (   )  [inline, protected, virtual]

DrawableGLI interface. Implements glift::SinglePrim. Definition at line 65 of file wrappedPrim.h. References glift::DrawableGLI::draw().

std::ostream & glift::GliftObject::err (   )  const [inline, protected, inherited]

a simpler way, just use the stream! only for always print, this one automatically adds the objects name Definition at line 111 of file gliftObject.h. References glift::GliftObject::m_err. Referenced by glift::CoordTrans::apply(), glift::SubTex::bindDef(), glift::PrimGL::bindIndices(), glift::SubdivPlanarQuadS::bindQuads(), glift::PrimGL::bindTexCoords(), glift::CoreTex::checkTexType(), glift::EmptyTex::copyToTex(), glift::CoreTex::CoreTex(), glift::FuncTex::FuncTex(), glift::Shader::genTexCoords(), glift::CoreTex::getDataf(), glift::CoreTex::getDataub(), glift::VertexProgARB::init(), glift::FragProgARB::init(), glift::PriorityTex::PriorityTex(), glift::VertexProgARB::reload(), glift::FragProgARB::reload(), glift::RenderableGLI::render(), glift::RenderPass::renderDef(), glift::EmptyTex::resetTexState(), glift::PixelShaderATI8K::setLocalConstf(), glift::TexCube::setTexData(), glift::EmptyTex::setTexData(), glift::ShadedPrim::ShadedPrim(), glift::TexConst::TexConst(), glift::TexCube::TexCube(), and glift::EmptyTex::tryToBindPbuff().

void glift::GliftObject::err (  const char *  where, const char *  when = 0 )  const [inline, protected, inherited]

error Definition at line 101 of file gliftObject.h. References glift::GliftObject::m_err. Referenced by glift::SubPBuff::enable().

std::ostream& glift::GliftObject::estr (   )  const [inline, protected, inherited]

this one just gives you the stream Definition at line 84 of file gliftObject.h. References glift::GliftObject::m_err. Referenced by glift::CoreTex::bindDef(), glift::Shader::bindDef(), glift::MultiTex::bindDef(), glift::EmptyTex::bindDef(), glift::DispList::compile(), glift::CoreTex::CoreTex(), glift::VertexProgARB::init(), glift::FragProgARB::init(), glift::MultiTex::releaseDef(), and glift::EmptyTex::releaseDef().

MultiPrimTexCoord * SinglePrim::genTexCoords (  const Shader *  shader  )  [virtual, inherited]

The handler function. Redefine if primitive should generate texture coordinates. Reimplemented from glift::RawPrim. Definition at line 42 of file rawPrim.cpp. References glift::Shader::genTexCoords(), glift::MultiPrimTexCoord, glift::MultiTexCoord, and glift::SinglePrim::scale().

virtual std::ostream* glift::GliftObject::getErrStream (   )  const [inline, virtual, inherited]

Where are gl errors going? Definition at line 49 of file gliftObject.h. References glift::GliftObject::m_err. Referenced by glift::getProgShaderFromFile(), and glift::getProgShaderFromText().

bool GliftObject::glerr (  const char *  where, const char *  when = 0 )  const [protected, inherited]

gl error report only in debug mode, only if there is an error, if so return true Definition at line 31 of file gliftObject.cpp. References glGetError(), and GLuint. Referenced by RenderState2D::bindDef(), glift::NormalAttrib< VAT >::disableDef(), glift::IndexAttrib< VAT >::disableDef(), glift::TexCoordAttrib< VAT >::disableDef(), glift::VertAttrib< VAT >::disableDef(), glift::GenDrawAttrib< VAT >::disableDef(), glift::DrawAlgImm::draw(), glift::DrawAlgArr::draw(), glift::ShadedPrim::drawDef(), glift::NormalAttrib< VAT >::enableDef(), glift::IndexAttrib< VAT >::enableDef(), glift::TexCoordAttrib< VAT >::enableDef(), glift::VertAttrib< VAT >::enableDef(), glift::GenDrawAttrib< VAT >::enableDef(), and RenderState2D::releaseDef().

virtual bool glift::WrappedPrim::hasTexCoords (   )  const [inline, virtual]

Texture coordinate interface. Implements glift::RawPrim. Definition at line 50 of file wrappedPrim.h.

void glift::WrappedPrim::init (  PrimGL *  prim  )  [inline, protected]

Definition at line 68 of file wrappedPrim.h. Referenced by glift::PlanarQuad::PlanarQuad(), and glift::SubdivPlanarQuadS::SubdivPlanarQuadS().

virtual bool glift::DrawableGLI::isCompiled (   )  const [inline, protected, virtual, inherited]

Redefine this for specific draw functions. Implements glift::Compilable. Definition at line 34 of file drawableGLI.h. Referenced by glift::PrimGL::bindIndices(), and glift::PrimGL::bindTexCoords().

virtual int glift::WrappedPrim::numVerts (   )  const [inline, virtual]

Implements glift::SinglePrim. Definition at line 49 of file wrappedPrim.h. Referenced by glift::SubdivPlanarQuadS::bindQuads().

WrappedPrim& glift::WrappedPrim::operator= (  const WrappedPrim &  rhs  )  [inline, protected]

Definition at line 63 of file wrappedPrim.h. References m_prim.

virtual void glift::WrappedPrim::releaseIndices (   )  [inline, virtual]

Implements glift::RawPrim. Definition at line 56 of file wrappedPrim.h.

virtual void glift::WrappedPrim::releaseTexCoords (   )  [inline, virtual]

Implements glift::RawPrim. Definition at line 57 of file wrappedPrim.h.

virtual const gutz::vec3f& glift::WrappedPrim::scale (   )  const [inline, protected, virtual]

Implements glift::SinglePrim. Definition at line 67 of file wrappedPrim.h.

virtual void glift::GliftObject::setErrStream (  std::ostream *  os  )  [inline, virtual, inherited]

Where do you want gl errors to go? they must go somewhere, so don't set it to zero please. Definition at line 44 of file gliftObject.h. References glift::GliftObject::m_err. Referenced by glift::getProgShaderFromFile(), and glift::getProgShaderFromText().

virtual const gutz::arrayo2f& glift::WrappedPrim::texCoord (  int  t  )  const [inline, virtual]

Implements glift::SinglePrim. Definition at line 48 of file wrappedPrim.h. References t.

virtual const gutz::arrayo2f& glift::WrappedPrim::texCoord (   )  const [inline, virtual]

Acessors. Implements glift::SinglePrim. Definition at line 47 of file wrappedPrim.h.

virtual const gutz::arrayo2f& glift::WrappedPrim::vert (   )  const [inline, virtual]

Definition at line 46 of file wrappedPrim.h.

---

Member Data Documentation

std::ostream* glift::GliftObject::m_err [mutable, protected, inherited]

Definition at line 87 of file gliftObject.h. Referenced by glift::GliftObject::derr(), glift::GliftObject::err(), glift::GliftObject::estr(), glift::GliftObject::getErrStream(), glift::GliftObject::GliftObject(), and glift::GliftObject::setErrStream().

---

The documentation for this class was generated from the following file:

• wrappedPrim.h

---
