Yong Ge and Sanping Li and V. Chris Lakhan and Arko Lucieer.
Exploring Uncertainty in Remotely Sensed Data with Parallel Coordinate Plots.
In International Journal of Applied Earth Observation and Geoinformation, vol. 11, no. 6, pp. 413--422, 2009.


Links:

Abstract:

The existence of uncertainty in classified remotely sensed data necessitates the application of enhanced techniques for identifying and visualizing the various degrees of uncertainty. This paper, therefore, applies the multidimensional graphical data analysis technique of parallel coordinate plots (PCP) to visualize the uncertainty in Landsat Thematic Mapper (TM) data classified by the Maximum Likelihood Classifier (MLC) and Fuzzy C-Means (FCM). The Landsat TM data are from the Yellow River Delta, Shandong Province, China. Image classification with MLC and FCM provides the probability vector and fuzzy membership vector of each pixel. Based on these vectors, the Shannon's entropy (S.E.) of each pixel is calculated. PCPs are then produced for each classification output. The PCP axes denote the posterior probability vector and fuzzy membership vector and two additional axes represent S.E. and the associated degree of uncertainty. The PCPs highlight the distribution of probability values of different land cover types for each pixel, and also reflect the status of pixels with different degrees of uncertainty. Brushing functionality is then added to PCP visualization in order to highlight selected pixels of interest. This not only reduces the visualization uncertainty, but also provides invaluable information on the positional and spectral characteristics of targeted pixels.

Bibtex:

@Article{        ge:2009:EUPC,
  author = 	 {Yong Ge and Sanping Li and V. Chris Lakhan and Arko
                  Lucieer},
  title = 	 {Exploring Uncertainty in Remotely Sensed Data with
                  Parallel Coordinate Plots},
  journal = 	 {International Journal of Applied Earth Observation
                  and Geoinformation},
  year = 	 {2009},
  volume = 	 {11},
  number = 	 {6},
  pages = 	 {413--422},
}
