K. Lowell and B. Christy and K. Benke and G. Day.
Modelling Fundamentals and the Quantification and Spatial Presentation of Uncertainty.
In Journal of Spatial Science, vol. 56, no. 2, pp. 185--201, 2011.


Links:

Abstract:

The fundamental nature of two different types of models was examined relative to how spatial uncertainty can be quantified and represented for communication to users of model outputs. One model was a complex systems-based landscape model driven by hydrological dynamics whose calibration is an iterative semi-objective process. The other is a crop-specific landscape suitability model that is calibrated using expert knowledge. How fundamental model differences impact the type of uncertainty information that can be produced is discussed as are difficulties in producing such information. Finally, commonalities between the two approaches relative to uncertainty are discussed

Bibtex:

@Article{        lowell:2011:MFQS,
  author = 	 {K. Lowell and B. Christy and K. Benke and G. Day},
  title = 	 {Modelling Fundamentals and the Quantification and
                  Spatial Presentation of Uncertainty},
  journal = 	 {Journal of Spatial Science},
  year = 	 {2011},
  volume = 	 {56},
  number = 	 {2},
  pages = 	 {185--201},
}

Images:

References:

Aerts, J., Clarke, K., & Keuper, A. (2003) Testing popular visualisation techniques for representing model uncertainty. Cartography and Geographic Information Science, vol. 30,pp. 249-261.
Beard, K., & Mackaness, W. (1993) Visual access to data quality in geographic information systems. Cartographica, vol. 30, pp. 37-46.
Benke, K., Lowell, K., & Hamilton, A. (2008) Parameter uncertainty, sensitivity analysis and prediction error in a water-balance hydrological model. Mathematical and Computer Modelling, vol. 47, pp. 1134-1149.
Benke, K.K., & Pelizaro, C. (2010) A SpatialStatistical Approach to the Visualisation of Uncertainty in Land Suitability Analysis. Journal of Spatial Science, vol. 55, pp. 257-272.
Benke, K., Pelizaro, C., & Lowell, K. (2009) Uncertainty in Multi-Criteria Evaluation Techniques When Used for Land Suitability Analysis. In: Cao, W., White, J.W., & Wang, E., eds. Crop Modeling and Decision Support.Springer, Berlin, pp. 291-298.
Brown, J., & Heuvelink, G. (2007) The Data Uncertainty Engine (DUE): a software tool for assessing and simulating uncertain environmental variables. Computers & Geoiscience, vol. 33, pp. 172-190.
Chiew, F., Stewardson, M., & McMahon, T. (1993) Comparison of six rainfall-runoff modelling approaches. Journal of Hydrology, vol. 147, pp. 1-36.
Ehlschlaeger, C., Shortridge, A., & Goodchild, M. (1997) Visualizing spatial data uncertainty using animation. Computers and Geosciences, vol. 23, pp. 387-395.
Hahn, E. (2003) Decision-making with uncertain judgements: a stochastic formulation of the Analytic Hierarchy Process. Decision Science, vol. 34, pp. 443-466.
Haines, L. (1998) A statistical approach to the Analytic Hierarchy Process with interval judgements. (I) Distributions on feasible regions. European Journal of Operational Research, vol. 110, pp. 112-125.
Herath, G., & Prato, T. (2006) Using MultiCriteria Decision Analysis in Natural Resource Management, Ashgate, Hampshire.
Hossain, H., Sposito, V., & Evans, C. (2006) Sustainable land resource assessment in regional and urban systems. Applied GISI, vol. 2, pp. 24.1-24.21.
Iman, R., & Conover, W. (1983) A Modern Approach to Statistics, Wiley, New York.
Jablonsky, J. (2005) Measuring efficiency of production units by AHP Models. Proceedings of International Symposium on the Analytic Hierarchy Process 2005, Honolulu, Hawaii, July; CD-ROM.
Johnson, C., & Sanderson, A. (2003) A next step: visualizing errors and uncertainty. IEEE Computer Graphics and Applications, vol. 23, pp. 6-10.
Kardos, J., Benwell, G., & Moore, A. (2005) The visualisation of uncertainty for spatially referenced census data using hierarchical tessellations. Transactions in GIS, vol. 9, pp. 19-34.
Lowell, K., Christy, B., Pelizaro, C., Barlow, K., O'Leary, G., & Pettit, C. (2008) Analysing and Creating Maps that Indicate the Impacts of Land-Use Change. Final Report. State of Victoria, Department of Primary Industries.45 pp.
Nash, J., & Sutcliffe, J. (1970) River flow forecasting through conceptual models, 1.A discussion of principles. Journal of Hydrology, vol. 10, pp. 282-290.
Pebesma, E., de Jong, K., & Briggs, D. (2007) Interactive visualisation of uncertainty spatial and spatio-temporal data under different scenarios: an air quality example. International Journal of Geographical Information Science, vol. 21, pp. 515-527.
Saaty, T.L. (1994) Fundamentals of Decision Making, RWS Publications, Pittsburgh.
Sposito, V., & Benke, K. (2010) Climate Change Impacts on Land Use: VCCAP Final Technical Report. Victorian Climate Change Adaptation Program, State of Victoria, Department of Primary Industries. 54 pp.
Tan, M., & Chen, J. (2008) Visualization of uncertainty associatecx with sopatial prediction of continuous variables using HSI color model (sic): a case study of prediction of pH for topsoil in peri-urban Beijing, China. Journal of Forestry Research, vol. 19, pp. 319-322.
van Oort, P. (2005) Do users ignore spatial data quality? A decision-theoretic perspective. Risk Analysis, vol. 185, pp. 1599-1610.
Weeks, A., Christy, B., Lowell, K., & Beverly, C. (2008) The catchment analysis tool: demonstrating the benefits of interconnected biophysical models. Chapter 4. Landscape Analysis and Visualisation - Spatial Models for Natural Resource Management and Planning. Springer, Berlin, pp. 49-71.
Whitaker, R. (2007) Validation examples of the analytic hierarchy process and analytic network process. Mathematical and Computer Modelling, vol. 46, pp. 840-859.
Wijnmalen, D.J.D. (2007) Analysis of benefits, opportunities, costs and risks (BOCR) with the AHP-ANP: a critical validation. Mathematical and Computer Modelling, vol. 46, pp. 892-905.
Wischmeier, W., & Smith, D. (1978) Predicting Rainfall Erosion Losses: A Guide to Conservation Planning. Agriculture Handbook No. 537, USDA-SEA United States Government Printing Office, Washington DC. 58pp.
