cs6620 Project 3

Abe Stephens

Required Image

(0.228 seconds with 4 threads. 0.595 seconds with one thread)

Creative Image

This is a Menger Sponge with several internal point lights on top of a disc. On top of the sponge is a ring about a sphere

This is a 3-level recusion Menger Sponge rendered with ambient occlusion and multisampled.

Extra Images

Height Data of Rensselaer County NY. (3m data from eight quads resampled to 200x292)
Hudson river is in the foreground.

Description

Performance template may be found here.

I am currently hard coding the scene into the executable front ends that invoke the renderer. I added several camera movement functions to my code so that I can interactively move the camera about the scene.

I implemented the extra image by downloading eight quads in sdts format and converted them to dem format with a another tool (google search sdts2dem.c). Next I stitched the dem files together with some of my own software and produced a floating point 2d nrrd. I decided I was interested in a zoomed out view, so I downsampled the data considerably.

Time spent: 4-5 days.
